| Product model | MT-GS1224EF |
| Standards and protocols | IEEE802.3、IEEE 802.3u、IEEE802.3ab、IEEE 802.3x |
| standard configuration |
24 10/100/1000M RJ-45 MDI/MDI-X port, 2 gigabit SFP port |
| Chipsets | Realtek RTL8382L |
| Flash | 16Mbit |
| transmit rate | 38.7Mpps |
| backboard bandwidth | 52Gbps |
| Forward rate |
10Mbps：14880pps；100Mbps：148800pps； 1000Mbps：1488000pps |
| swap mode | Store-and-Forward |
| MAC address table | 8K |
| Dimension | 440*220*44 (mm) |
| Consumption | 15W |
| Energy conservation design | Fanless |
| LED light | power 、Link/Act、1000Mbps |
|
environment temperature | Operating temperature: 0-50℃ Storage temperature:-40-70℃ |
|
environment humidity |
Operating humidity:10%-90% non-condensing Storage humidity:5%-90% non-condensing |
| Input power Consumption |
Internal Power Supply Input：100-240V/AC，50-60Hz； output：12V/2A Consumption：≤15W |
