Elder Care Intelligent Camera Product Specification Sheet V1.0.0
| Applicable Scenarios | Indoor | |
| Operating System | Linux | |
Configuration Standards | ROM | 16MB |
| RAM | 64MB | |
Sensor Parameters | Pixel | 2 million (1920*1080) |
| Image Sensor Specifications | 1/3" CMOS | |
| Photosensitivity performance | Ordinary | |
| Frame Rate | 20 frames per second | |
| Effective Pixels | 2 million, 1920*1080 | |
| Digital Wide Dynamic Range | Support; Wide Dynamic Range: 72dB; | |
| Digital Noise Reduction | 3D Digital Noise Reduction | |
| Lens Specifications | focal length | 4mm |
| Variable Zoom | No Zoom | |
| Aperture | F2.0 | |
| Horizontal Field of View | 87° | |
| Vertical Field of View | 46° | |
| Diagonal perspective | 104° | |
| Fill light | Infrared Illumination | Support:Number of 940nm; infrared fill lights: 8; Infrared fill light power: 0.15W per piece; |
| Warm light bulb | Reserved | |
Illuminance Parameter | Minimum Illumination | 0.01Lux(Color Mode) |
| 0.001Lux(Black and White Mode) | ||
| 0Lux(Turn on the fill light) | ||
| Encoding | Video Encoding | H.265/264 |
| Audio encoding | G.711A | |
| Video Bitrate | True 2-megapixel resolution; average bitrate ≤ 1560 Kbps, peak bitrate ≤1920 Kbps. | |
| Dynamic Bitrate Adjustment | Support | |
| Night Vision Mode | Infrared Night Vision | Support; Night Vision Switching Mode: Auto Switching/Manual Switching; Infrared Night Vision Distance: ≥7m |
| Discrimination Method | Soft Photosensitive | |
| Speech Parameters | Voice Communication | Support; Supports full duplex; |
| Echo Cancellation | Support | |
| Microphone | Support; Built-in 1 mic; Microphone sensitivity: -42dB±3; Pickup distance: ≥5m; | |
| Speaker | Support; Built-in; Speaker power: 1W; | |
| Standard Features | Add Device | Support |
| Live streaming | Support | |
| Listen | Support | |
| Screenshot | Support | |
| Video recording | Support | |
| Message Push | Support | |
| Share | Support | |
| Storage | Support | |
| Playback | Support | |
| Alert | Support | |
| Cruise | Support | |
| AI capabilities | Human detection, tracking | Support |
| Hazard Area Marking/Electron ic Fence | Support | |
| Fall Detection/Recog nition | Support | |
| Scheduled Reminders | Support | |
| No notifications have appeared. | Support | |
Value-added services | Cloud Storage | Support |
| Telephone Alert | Support | |
| Alarm Contact Expansion | Support | |
| 内容订阅 | Support | |
| Network | Wi-Fi | Support 2.4g, wifi6 |
| Distribution Network Logic | Bluetooth broadcasting, pairing; QR code network configuration. | |
| Function Parameters | Device Name Modification | Support |
| Equipment Equipment Inquiry | Support | |
| Resolution Switching | Support | |
| Turn on/off the camera | Support Physical Occlusion | |
| Screen rotation | Support | |
| Video playback | Cloud storage, TF card | |
| Device Sleep RTC Clock | None | |
| Server Clock Synchronization | Support | |
| Environmental Parameters | Operating Temperature | -10℃~50℃ |
| Storage Temperature | -30℃~60℃ | |
| Relative Humidity | 0% to 95%, non-condensing | |
| Atmospheric Pressure | 86kPa to 106kPa | |
| Attachment | Power Supply | DC 5V/1.5A（type-C） |
| Mounting bracket (accessory) | Specification: Support Kit; Pitch Angle: 100; Swivel Angle: 350; | |
Instruction Manual Certificate of Conformity | Standard | |
| Storage (Expansion) | TF card | Cloud Storage, TF Card (MAX 128GB) |
| Structure | Materials | Engineering Plastics |
| Installation | Installation Method | Desktop placement, wall mounting, ceiling suspension. |
| Installation Scenario | Indoor living room, hallway, balcony, etc. | |
| Packaging | Form | Cardboard box |
| Size | 78*78*133mm | |
